Here's something a little different. A DX for Road Hog's follow-up machine, Road Hog 2- I'm Back. Set to £10/25p/92% Considered doing this machine for ages, so decided to take the plunge and get it done. Now, Road Hog, Road Hog 2, and Hot Rod are all done! The native resolution on this is quite large, so would suggest using 'Shrink To Fit', in MFME's options. Use MFME6.1 to play. Credits go out to tthe following people: Mark8864 - For the original DX. SPA - For the flier that was used. The shortcuts for this are: Cancel/Collect - ` Hold/Nudge - 1 Hold/Nudge/HI - 2 Hold/Nudge/LO - 3 Feature Exchange - E or F Start/Gamble - Space Accept Bid - A Reject Bid - R £1 Insert - 0 Have fun! Road Hog 2 I'm Back DX.zip
-
Hi Guys I am happy to release my first ever MPU2 layout called Hi-lights. A fantastic game back in 1981! Thanks to the following people on this site for making it possible for me to recreate for MFME v19: Pete W for providing the roms and sending me some old pics. Launton for providing the fruit symbols. Line Up Chris for hosting the video which helped me work out the reel order. Richy1976 for putting together the authentic coin sounds. And of course Wizard for MFME!! SHORTCUTS 10p in (9) 10 Token in (0) 50p in (8) Left Start/Collect (Shift) (Num 7) Nudge 1 UP (Q) (Num Del) Nudge 2 UP (W) (Num 5) Nudge 3 UP (E) (Backspace) Hold 1 (1) (Num 1) Hold 2 (2) (Num 2) Hold 3 (1) (Num 3) Cancel (C) (Num 7) Nudge 1 Down (A) (Num Nudge 2 Down (S) (Num 6) Nudge 3 Down (D) (Num *) Right Start/Gamble (space) (enter) Volume +/- Download: (Requires MFME v19) </Frig> Hi-Lights V1.1.zip
-
Hi Guys I finally finished off Spot Light this morning, so it is now ready for everyone to enjoy using MFMEv19.4. A big thanks to the following people on this site, for the resources they provided. Launton for roms, and base reel symbols. Pete W for uploading the Spot Light picture to the gallery. And Richy100 for the additional, very interesting flyer that I put in the download folder. Additional thanks go to Richy1976(fruit-emu.com) for coin sounds. And finally a huge thanks goes to Wizard, for testing, additional technical help, and of course for providing MFME to all of us, and all his continuous support:)) Short cuts are in the Read Me file. Download: Spot Light v1.zip Have fun guys! </Frig>
-
Hi, just bought a barcrest full of beans and it worked when I bought it. Got it home and nothing. Checked fuse in plug and inside power supply and both ok. Power supply makes a click when you click the switch but nothing, no lights at all. Can't smell any burning. Does this mean the mpu5 power supply needs changed? Thanks.
-
Can't wait to start exploring and reliving my youth on here.
-
Hello fellow members I am hoping one of you lovely people can help me find this Fruit machine ROM. Picture attached Thanks for any help in tracking this down
-
From the album: Gallery of those I have owned.
© S.Reed
-
From the album: Gallery of those I have owned.
© S.Reed
-
Hello, I’m new on this website/form and I’m wondering if someone could help my sold the problem i have with my barcrest machine. After my friends plays on it it stopt working, when i try to reset the machine nothing happens and the same error code keeps coming. Also when I pull the switch of memory reset nothing happens. Now I bought a new MPU5 board but with this board the machine does nothing only the board will flash red sometimes. Does anyone know how I can fix this issue, I like the machine so much.. that I keep trying but nothing helped yet. Regards, Matthijs
-
Hi Guys This one is specially for RobT, who supported this project with Roms, pictures and valuable feedback. 1981 Barcrest Rock On DX - MPU2 You will need the latest version of MFME which is currently v19.4, due to an update Mr Wizard did on MPU2/3 emulation, that improves the performance of this machine and others running the same tech. Thanks goes to RobT for his fantastic support! Launton for his great quality reel fruit scans, and especially for sending me a nice Apple:) Thanks also goes to Hitthesix for setting this project up, Richy1976 for organizing the sound files, and finally Mr Wizard for the amazing MFME and the fantastic updates he has done:)) Here is the layout: ROCK-ON v1.zip Long Live MFME! </Frig>
-
I got a broken Barcrest Crown Jewels 2000, but I'm trying to fix it. I have fixed a short circuit in MPU5 due to capacitor C12 has shorted. But now I have to fix the 2 red and 1 green error -
Seen these come up on eBay just curious on how old they really are, incording to Barcrest Games list (posted here) it is not an MPU1. So how old is it? Quite nice looking art works
-
Hi all, I've been lurking here for a couple of days and read up on much of what is available here on the Barcrest MPU3. Thank you so much Midibob for all the info you so freely shared! I have owned a Barcrest Royal Diamonds for years, acquired it in '97. It was missing a 7 segment display (easily built) and the battery was bad (easily replaced). No real damage to the board nor the transistors. One 74LSxxx was bad. When I couldn't figure it out I (get this) called Barcrest, got connected to their Technical Department and ended up talking to a guy who helped design this particular game! His tips quickly led to a faulty 74LS12 (if I remember correctly) and it has been playing ever since. Well, that is; it was stored in the back of the garage for the last couple of years and then, on trying it a couple of months ago, it wouldn't budge of course. I have some experience in repairing electronics, am a HAM, and have restored a couple of Solid State pinball CPU boards (most of 'm damaged by battery leakage). So, after reading up here on the MPU3 stories I tackled the RD last weekend. It was ever so simple... the battery was flat but when connected to a separate Power Supply it charged neatly and holds its voltage for at least a couple of days. Checking the Test Points with a multimeter and a service scope gave a funny reading on the RESET line: it stayed low. Well, the board should not be resetting continuously and a quick look at the schematic suggested bad transistors or a bad Tantalium cap. I do not have any of the transistors in my junk box, but a reasonably fresh 10uF Tantalium cap was. Replaced it and Presto! If life would only be so simple more often 😉 Tested the game this morning and after resetting all the readings seem to indicate everything is working. The only things left now: I have a wiring diagram for the Royal Casino which is probably very like the Royal Diamonds but I'd love one for the RD. Also, the green diamond lamps all light up just as bright as all the others but still they are poorly visible. I wonder if the glas is dirty on the inside? Hope this will do as an introduction. Now everything is running I'll probably won't be visiting daily, but I thought it only polite to let you know how the forum, the info and you people are appreciated! BartW. PS: Oh yeah, one thing that has been bugging me: what the heck is the 'Aerial' used for that is tied into the Harness??
-
From the album: Some things to play with...
© Coinrunner
-
Evening all Been playing Pot Black ROM for a while. Was wondering if anyone has one of these? Maybe looking to sell? Thanks Steven
-
I'm hoping someone can help I've got a sit down elvis machine that is running as a rio machine, when it starts up the game is obstructed by 'DATAPORT 7.1' message ad shown in the picture. Does anyone know how to solve this? Also Im looking into putting other games on the hard drive where would I get them and how would I do this?
-
Hi - Not been about for a longtime..... You know how it is, just too many things to do :-( To keep some of my machine's I have had to agree to give-up some of my storage space. This means 3 machines have to go! Addams Family - £5 with decals, also have £25 chip and decals. all working fine Brenco - King Strike, 1p play, takes old 10p & 2p (Retro Nostalgia) a little noisy sometimes. working and pays out. Taito, Space Invaders - Just a shell, a project that I bought & haven't touched..... There you go, will list on Saturday, if anyone is interested get in touch. Thanks -
Hi there, I'm new here from the island of Malta. Just got two Barcrest machines that I'm looking to restore. Jp
-
Hi my name is viktor from Hungary. I ve just got a barcrest jolly joker II fully playable , but the alphanumeric display doesnt show much, its sometimes working but not correctly , its just light on to an unknown letter and stay so if i turn it down it will gone. So my question is where can i get spare parts for this machine, a userguide would be awsome to , and i also need a new power supply for another barcrest machine that is functioning with the jokers power supply i dont know the name but the same supply is okey what the joker have. Thank you very much !!!!
-
twintimer (dutch version) -
Barcrest Calamari Club MPU4 LED display
baby gee posted a topic in INTRODUCTIONS (NEW MEMBERS FORUM)
Hi there, I just got a barcrest calamari club mpu4 fruit machine but the display is not working, can anyone help -
Hi there, can anyone help I have no led display
-
Hello Folks, I'm selling a freshly restored and perfectly working fruit machine : - BARCREST Ambassador Gum 3000 Mpu4 mod4 - Fully functioning prizes and bubble gum fruit machine. A very rare one due to France legislation ! Lights, reels, coins, sound and GUM distributor are fully tested and are working perfectly. MPU4 mod 4 mother board has been restored and upgraded with new and outside pcb battery. This one will last a very long time without the battery leak problem ! This Ambassador Gum 3000 contains : -1x full chassis with perfect glass, lights, reels, speaker, coin meter and red bubble gum distributor ! -1x MPU4 mod4 upgraded -1x Game cartridge AG3.0 for full features (multi-gum, multi-coins,...) - Several 10F playable coins -1x PSU cable (FR or UK plug just ask) 600€ Due to weight, no shipping, no return, you'll have to pick it up here close to Paris. Thanks Please contact me via PM, I'd be glad to answer any question. -
Hi, Here's the beginning of my second MPU4 mod4 restoration for a Barcrest Ambassador Gum 1000 : this board was the worst of the 4 boards, really nasty battery leakage, lot's of broken tracks. Burn signs on both ULN2803A and resistor pack 22k. I'll come back with the fix list asap. Cheers
-
Hi, A friend of mine bought 3 fruit machines Ambassador Gum, 3 with working bubblegum distributor, they where made for France or Belgium where money games are forbidden... Only one did turn on, the bassador 1000. The 3000 doesn't boot and the extra AG1000 will be the next project. Here's the restoration project for the Ambassador Gum 3000, MPU4 mod4. Following www.booze.net advices, thanks a million times Paul you convince me to do it, the battery has been removed, changed, and stuck outside the box. Mine had severe blue / greenish leakage damages from battery down to dataport. Audio amp, volume VR1 and neighbours look pretty bad.
